COM4LAB Course: Digital Technology II

The COM4LAB course Digital Technology II is the second course on the fundamentals of digital technology. This course explores several flip-flop types and various flip-flop applications such as counters, shift registers and parallel-serial converters. The course, comprising 12 chapters, also examines the troubleshooting procedure in detail.

The course covers the following topics:

• bistable multivibrators

  SR flip-flop – clocked SR flip-flop – D flip-flop – JK flip-flop – JK master-slave flip-flop

• monostable and astable multivibrator
• Schmitt trigger
• flip-flop applications

  frequency divider – counter – shift register – parallel-serial converter

The course …

• can be displayed and filled out on your own tablet/smartphone/laptop.
• is platform-independent - a current browser is sufficient.
• can be distributed to students via QR codes.
• enables interactive experimenting: The measured values from the Master Unit are automatically made available for evaluation in tables and diagrams. The analysis and documentation of the experiment on the student device can be done at school or at home.
• can be edited and thus adapted to your own lesson plan.
